RFID UHF Short Range Integrated Reader
Model NO：
MR6261E
Key Features MR6261E UHF RFID Reader base on new generation reader technology platform development which is combine UHF RFID advanced technology and many years reader application base experience. This reader is more stable and can use in various applications.
Reader Support ISO18000-6C, EPC G2 tag, It support Multi tag query, read, write, selection, Single tag read, write, lock, kill
User can set the parameter of interface, IP address, Jump Frequency point, output power, reading indication, working mode etc; When in Timing or Trigger mode, can set the parameter of reading card type, read area, address, length, output method, output interface
Support Ethernet, RS232 and RS485 both-way communication interface, protocol compliant to《UHF RFID reader and PC communication protocol V2.0》；Also reader support Weigand single way data transmission interface, format compliant to Wiegand 26 and Wigand 34 interface protocol
Support timing read or trigger read working mode，all tags in query area can be read according to set address and length，read data direct output or buffer. Read data can selected for filtering same tag. Output data interface can be any one of interface or multiple interface，meanwhile can configure relay.
Data buffer have power-off function preserves.
Support web network server function, can set working parameter on Web page, reader also support Serial port and RJ45 port upgrade in the application firmware.
Maintenance Guide:
Maintenance Guide:To ensure the long-term stable operation of the short range RFID reader, please refer to the following maintenance recommendations:
Daily Cleaning: Wipe the device housing with a soft, dry cloth to prevent dust accumulation that could affect heat dissipation and performance. Never use corrosive chemicals to clean the reader.
Regularly Check Interfaces and Cables: Ensure the interfaces are secure and reliable to prevent poor contact that could cause read/write failures.
Software Parameter Backup: For frequently adjusted operating modes and reading parameters, it is recommended to regularly back up the configuration file to quickly restore the original settings when the device is restored or upgraded.
Environmental Control: Avoid prolonged operation in high-temperature, high-humidity, or strong electromagnetic interference environments to extend the device's lifespan.
Power Failure Protection: The device's data buffer has a power-failure protection function, but it is still recommended to turn off the power and save data before long-term non-use to ensure information security.
Why Choose Us?
Why Choose Us?Expertise and Experience: We have long specialized in RFID system development and sales, providing one-stop, end-to-end solutions for short range UHF RFID readers and extensive project implementation experience.
High-Quality Products and Wholesale Advantages: All products are rigorously tested for stable and reliable performance. We offer both wholesale and custom RFID UHF reader solutions to meet both large-scale procurement and customized business needs.
Cost-Effective Products: Direct factory pricing ensures high performance and affordable costs for our UHF RFID integrated readers, helping businesses reduce overall operating costs.
Comprehensive Technical Support: We provide comprehensive technical support from model selection, installation, commissioning, and maintenance to ensure the smooth implementation of each project and reduce operational burdens.
Quick Response and After-Sales Guarantee: Our customer service and technical teams offer responsive after-sales services, including repairs, parameter tuning, and software upgrades, ensuring long-term stable operation of our equipment.
Parameters | Items | Parameter |
| Frequency | US（902～928MHz）, China（920～925MHz）, |
| Supported RFID Tag Protocols | ISO18000-6C,EPC G2 |
| Reader Protocols | MarktraceRFID reader protocol, firmware upgradable |
| RF Power | 0～30dBm adjustable |
| Sensitivity | -80dBm |
| Antenna | 3dBi Circular polarization antenna |
| Read Speed | Multi tag-200pcs/second, single tag 2000 times/minute |
| Reading Range | 3 m |
| Processor | ARM CORTEX M3 100M CPU |
| Memory | 16KB tag data memory |
| Data Interface | 100M Ethernet Interface (TCP/IP) RS232,RS485, Wiegand 26/34 1 set input and 1 set output（TTL),1 set relay |
| Software SDK | C# and C++ |
| Power Supply | DC+9V～+15V |
| Indicators | Buzzer, LED |
| Working Temp. | -20～60℃ |
| Weight | 0.46kg |
| Dimensions | 154.6*106.5*26.5mm |
| Color | Black |
