RFID UHF Middle Range Integrated Reader
Model NO：
MR6221E
Key Features MR6221E UHF RFID Reader base on new generation reader technology platform development which is combine UHF RFID advanced technology and many years reader application base experience. This reader is more stable and can use in various applications.
Reader Support ISO18000-6C, EPC G2 tag, It support Multi tag query, read, write, selection, Single tag read, write, lock, kill.
User can set the parameter of interface, IP address, Jump Frequency point, output power, reading indication, working mode etc; When in Timing or Trigger mode, can set the parameter of reading card type, read area, address, length, output method, output interface.
Support Ethernet, RS232 and RS485 both-way communication interface, protocol compliant to《UHF RFID reader and PC communication protocol V2.0》；Also reader support Weigand single way data transmission interface, format compliant to Wiegand 26 and Wigand 34 interface protocol.
Support timing read or trigger read working mode，all tags in query area can be read according to set address and length，read data direct output or buffer. Read data can selected for filtering same tag. Output data interface can be any one of interface or multiple interface，meanwhile can configure relay.
Applications:
Applications:1. Intelligent traffic management such as ETC, custom clearance, parking lot, and automatic weighing
2. Commercial parking lots, such as supermarkets, commercial buildings, or non-commercial parking lots, such as residential areas, residences, etc.
Maintenance and Usage Guide:
Maintenance and Usage Guide:To ensure the long-term stable operation of the UHF integrated reader, users are advised to pay attention to the following maintenance details during use:
Installation environment: Avoid prolonged use in areas with high humidity, strong magnetic interference, or extreme temperatures.
Regular cleaning: Keep the reader surface clean to avoid dust and oil that may affect performance. Firmware Update: Regularly check the firmware version and update to the latest version for optimal performance and security.
Interface Inspection: Regularly check the network and power interfaces to ensure they are secure and not loose.
Avoid Overload: Optimize the read area and power settings to avoid overloading that may cause device overheating or performance degradation.
Following these maintenance recommendations can effectively extend the life of your device and ensure stable system operation.
Why choose us as your partner?
Why choose us as your partner?As a professional RFID UHF reader company and RFID UHF reader factory, we not only provide high-performance hardware but also offer end-to-end solutions, including:
One-stop supply: We offer a full range of products, from RFID tags to RFID readers, to meet the needs of various industries.
OEM/ODM customization: We can provide customized functions and designs based on your application scenarios.
Technical support: Our experienced R&D and after-sales teams ensure rapid response and problem resolution.
Global service network: We support international wholesale and export, with products exported to markets such as Europe, America, Southeast Asia, and the Middle East.
Strict quality control: We undergo multiple rounds of testing before shipment to ensure that every UHF integrated reader meets industry standards.
Parameters | Items | Parameter |
| Frequency | US（902～928MHz）, China（920～925MHz）, EU（865～868MHz）, other frequency selectable |
| Supported RFID Tag Protocols | ISO18000-6C,EPC G2 |
| Reader Protocols | MarktraceRFID reader protocol, firmware upgradable |
| RF Power | 0～30dBm adjustable |
| Sensitivity | -80dBm |
| Antenna | 9dBi linear polarization antenna |
| Read Speed | Multi tag-200pcs/second, single tag 2000 times/minute |
| Reading Range | 6 m |
| Processor | ARM CORTEX M3 100M CPU |
| Memory | 16KB tag data memory |
| Data Interface | 100M Ethernet Interface (TCP/IP) RS232,RS485, Wiegand 26/34 1 set input and 1 set output（TTL),1 set relay |
| Software SDK | C++ |
| Power Supply | DC+9V～+15V |
| Indicators | Buzzer |
| Environment Rating | IP65 |
| Working Temp. | -20～60℃ |
| Weight | 1.5kg |
| Dimensions | 280*280*68.5mm |
| Certifications | FCC, CE |
| Color | Gray |
