2.4GHz Active Tag
Model NO.：
MR3848
Key Features
Ultra-low-power, average working current<10uA.
Small size design suit for IT assets, valuable items, equipment and instruments
2.4G identify range can reach 80 meters, reading range adjustable via software.
Light sensor, alarm signal will send out once removed from object.
Parameters
Model No | MR3848 |
Type | Beacon type, MAX RF power 0dBm |
Inductive mode | Initiative transmit, transmit every 3 second |
Material | ABS, heat resistant ,Black Color |
Dimension | 42*18.2*7.3mm (without 3M) 3M layer thickness is 1.55mm |
Weight | 7g |
Battery | Battery life 3 years (signal time interval is 3s) |
IP Grade | IP54 |
Signal Modulation Mode | GFSK |
Communication Speed | 1Mbit/s |
Operating Frequency | 2.44GHz |
Quiescent Current | <3uA |
Average Current | <10uA |
Battery mode | CR1632 |
Operating Temp | -20℃~+45℃ |
Storage Temp | -30℃~65℃ |
Certifications | CE & FCC |
